The Balance Anti-Vibration Table gives a sensitive balance its own steady base. The balance stands on a scratch-resistant dark granite slab carried on shock-absorbing rubber mounts, while a separate black laminated top around it holds samples and notes without touching the slab. The internal working surface measures 400 x 450 mm.
| Parameter | Detail |
|---|---|
| Type | Anti-vibration weighing table, two-table construction |
| Weighing slab | Large, scratch-resistant dark granite; polished finish, easy to clean |
| Slab mounting | Shock-absorbing rubber mounts |
| Internal working surface | 400 x 450 mm |
| Surrounding work top | Black laminated, for resting samples or documents |
| Frame and feet | Lightweight tubular aluminium frame; adjustable levelling feet for uneven surfaces |
| Overall dimensions | 800 x 600 x 782 mm (W x D x H) |
| Net weight | 55 kg (table and work surface) |
| Assembly | Easy to assemble; all necessary tools supplied |
| Product code | SLE/LB/17 |
| Minimum order | 10 units |
| Dispatch | Usually within 7 to 10 working days |
| Supplied by | ScienceLab (Jain Scientific Equipments Pvt Ltd), Ambala, India |
Installing the station. Assemble the frame with the tools supplied and stand it in its final place before levelling. Turn the levelling feet until a spirit level laid on the granite reads level in both directions. Centre a balance such as the four-decimal analytical balance on the slab, level the balance itself, let it warm up and calibrate it there.
Bench against table. Put a balance on an ordinary bench with a sample in a plastic weighing boat and note how far the last digit wanders while someone walks past or closes a door. Repeat the same test on the granite slab. Students compare the spread of readings and explain where the vibration was absorbed.
Daily routine. Keep the vacuum desiccator, a Chattaway spatula and the notebook on the laminated surround, never on the granite. Wipe spills from the slab at once with a damp cloth and dry it, and recheck the level whenever the table has been moved or cleaned underneath.
A heavy stone slab is stiff and has a lot of mass, so small knocks barely move it and it does not flex under the balance. Granite also resists scratches, and its polished surface wipes clean easily after a spill.
The granite rests on rubber mounts on its own, apart from the laminated top around it. Leaning on that top, writing notes or setting a sample down there does not reach the balance. Keep the gap between the two clear, because anything bridging it passes vibration straight to the slab.
Choose a quiet corner away from doors, windows, air-conditioning outlets and walkways, and away from centrifuges, shakers or pumps. A ground-floor room or a spot beside a solid wall moves less than the middle of an upper floor. Keep it out of direct sunlight so the balance does not warm unevenly.
The table damps vibration from the floor, but drift also comes from air currents, a sample warmer or colder than the room, static charge on plastic containers and moisture uptake. Close the balance's draught shield if it has one, let samples reach room temperature and give the balance time to warm up.
Set the table in its final position first, then turn the adjustable feet until it stands firm without rocking and a spirit level on the granite reads level. Only then level the balance with its own feet, because moving the table later undoes both adjustments.
